StarTech.com
StarTech Multimode SC Fiber Ethernet Media Converter, 1000BASE-SX Gigabit Fiber Optic to Copper Bridge, 10/100/1000 Network, 550m, TAA
Multimode fiber Ethernet media converter extends & bridges copper networks - 10/100/1000 (Gigabit), 1000BASE-SX, 850nm, 550m (1084 ft), Unmanaged, MMF, SC, RJ45, Mounting Brackets, LFP, VLAN, ESD Surge + Contact & Air Protection, 2 Yr Warranty
Buy 2 Reams Get a Macy's or Home Depot Gift Card - Learn More
Item:
STCMCMGBSCMM055
- Converts and extends a Gigabit Ethernet fiber (1000Mbps) network over multimode fiber on 1000BASE-SX networks
- Provides a cost-effective Ethernet to fiber/copper to fiber link
- Supports a maximum distance of 550 m over multimode fiber-optic cable (SC connection)
- Compact design and wall mountable
- Non-blocking full wire-speed forwarding rate
- Provides DIP switch supporting Link Fault Pass-through function
- LED Indicators for simple Ethernet/fiber network link monitoring
- 850 nm wavelength
- Supports IEEE 802.1q Tag VLAN pass-through
Ships 6-10 Business Days
Checking for Also-Bought items, please wait...
Manufacturer:
StarTech.com
Catalog:
General Line (consumer) Catalog
Catalog page:
NEW
Manufacturer
StarTech.com
Manufacturer Part Number
MCMGBSCMM055
Manufacturer Website Address
https://www.startech.com
Brand Name
StarTech.com
Product Name
Gigabit Ethernet to SC Fiber Media Converter - 1000Base-SX - Multimode 550 m
Marketing Information
This fiber media converter extends a Gigabit Ethernet (1000Mbps) network up to 550 mover multimode fiber, on 1000BASE-SXnetworks. Extend your GbE network cost-effectively The fiber media converter offers a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernetnetwork infrastructures.The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation. Reliable and scalable network connectivity Supporting a maximum multimode fiber-optic cable distance of 550 meters (0.34 miles), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations over multimode fiber, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also offers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network. The MCMGBSCMM055 is backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer
Packaged Quantity
1 Each
Product Type
Transceiver/Media Converter
Manufacturer
StarTech.com
Manufacturer Part Number
MCMGBSCMM055
Manufacturer Website Address
https://www.startech.com
Brand Name
StarTech.com
Product Name
Gigabit Ethernet to SC Fiber Media Converter - 1000Base-SX - Multimode 550 m
Marketing Information
This fiber media converter extends a Gigabit Ethernet (1000Mbps) network up to 550 mover multimode fiber, on 1000BASE-SXnetworks. Extend your GbE network cost-effectively The fiber media converter offers a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernetnetwork infrastructures.The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation. Reliable and scalable network connectivity Supporting a maximum multimode fiber-optic cable distance of 550 meters (0.34 miles), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations over multimode fiber, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also offers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network. The MCMGBSCMM055 is backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer
Packaged Quantity
1 Each
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
1
Number of SC Ports
1
SC Port Type
Duplex
Media Type Supported
- Twisted Pair
- Optical Fiber
Fiber Mode Supported
Multi-mode
Fiber Optic Cable Wavelength
850 nm
Maximum Distance Supported
0.55 km
Ethernet Technology
Gigabit Ethernet
Network Technology
- 1000Base-T
- 1000Base-SX
- 1000Base-TX
- 10Base-T
Power Source
AC Adapter
Power Consumption
10 W
Plug/Connector Type
Type N
Form Factor
Wall Mountable
Height
1"
Width
3.8"
Depth
2.8"
Weight (Approximate)
7.10 oz
Package Contents
- Gigabit Ethernet to SC Fiber Media Converter - 1000Base-SX - Multimode 550 m
- 1 x Universal power adapter (NA/JP, UK, EU, ANZ)
- 1 x Quick-start guide
Environmentally Friendly
Yes
Environmental Certification
EU RoHS
Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 2
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin
Taiwan
TAA Compliant
Yes
End of Life Manual Availability
Yes
EU RoHS Declaration URL
https://media.startech.com/cms/pdfs/mcmgbscmm055_rohs.pdf
REACH Declaration URL
https://media.startech.com/cms/pdfs/mcmgbscmm055_rohs.pdf
REACH free of SVHC
Yes
WEEE Statement
https://media.startech.com/cms/pdfs/mcmgbscmm055_weee.pdf
2 Year
